Cisco 642-447 - Questions & Answers

Free preview · every answer includes a full explanation

Product page: https://prepkeys.com/642-447.html

Question 1
Multiple choice

Which three options correctly describe the role of a subsequent node in a Cisco Unified CallManager 5.0 cluster? (Choose three.)

A.

processes IP telephony calls

B.

collects CDRS

C.

replicates the database to other Cisco Unified CallManager servers

D.

maintains read-only copies of the configuration database

Question 2
Multiple choice

A Cisco Unified Communications Manager cluster contains a publisher and four subscriber nodes.
If the publisher becomes unavailable, which three of these statements are true? (Choose three.)

A.

All on-net calls are dropped.

B.

The Informix database automatically locks.

C.

All IP telephony devices continue to operate.

D.

New Cisco Unified Communications Manager devices can be configureD.

E.

Available Cisco Unified Communications Manager servers work from the local backup database.

F.

The Informix database will save configuration changes on subscribers to be uploaded to the publisher when available.

Question 3
Single choice

Which portion of the master Administrator account can be changed after installing using the CLI?

A.

privilege level

B.

username

C.

password

D.

username and password

Question 4
Multiple choice

Which three steps must be completed in order to assign a service URL to an IP phone button? (Choose three.)

A.

Add an IP phone service.

B.

Subscribe the phone to the service

C.

Associate a valid user profile with the phone.

D.

Assign the IP phone service partition to the CSS of the phone.

E.

Create a soft key template that includes a service URL and assign it to the phone.

F.

Create a phone button template that includes a service URL and assign it to the phone.

Question 5
Multiple choice

Which two features are advantages of deploying a cluster over WAN? (Choose two.)

A.

shared line appearances

B.

centralized DSP resources

C.

extension mobility within the cluster

D.

scalability up to 20 sites, if there is sufficient IP WAN bandwidth

E.

failover to co-resident Cisco Unified Call Manager Express platforms

Question 6
Single choice

The Show menu in which navigation window will allow you to determine the model, type of processors, and total memory in a Cisco Unified Communications Manager 6.0 server?

A.

Cisco Unified Communications Manager Administration

B.

Cisco Unified Communications Manager Serviceability

C.

Disaster Recovery System

D.

Platform Administration

E.

Cisco Unified Operating System Administration

Question 7
Single choice

The Ajax Corporation is designing an IP telephony network using Cisco MCS 7845 Series servers, each one capable of supporting 7500 devices. The design must meet these requirements:

(1) be cost-effective
(2) support up to 7500 phones (3) provide a minimal level of redundancy

Which configuration will meet Ajax Corporation's needs?

A.

two Cisco Unified Communications Manager servers:
1 publisher and TFTP server combined
1 primary subscriber

B.

three Cisco Unified Communications Manager servers:
1 publisher and TFTP server combined
1 primary subscriber
1 backup subscriber

C.

four Cisco Unified Communications Manager servers:
1 publisher
1 TFTP server
1 primary subscriber
1 backup subscriber

D.

five Cisco Unified Communications Manager servers:
1 publisher
1 TFTP server
1 primary subscriber
2 backup subscribers

Question 8
Single choice

In a Cisco Unified Communications Manager 8.0 cluster, how is database replication accomplished for run-time data?

A.

Replication is through a master database from publisher to all active subscribers.

B.

Replication is a mesh from subscriber to subscriber and subscriber to publisher.

C.

Replication is a hybrid using both a hierarchical and mesh process.

D.

Replication is a push from subscriber to publisher.

Question 9
Single choice

What is one of the features of deploying Cisco Unified Communications Manager servers in a 1:1 redundancy design?

A.

When the primary servers approach 100% utilization, the backup servers can take over a portion of the load

B.

If a single primary server fails, multiple servers can distribute the load generated by users reregistering from the failed server.

C.

If multiple servers fail concurrently, the resulting load generated by users reregistering does not overwhelm the dedicated backup servers due to 1:1 redundancy.

D.

Recovery happens faster when the load generated by the users from a failed server is spread over more than one backup server

Question 10
Single choice

The Ajax Corporation is designing an IP telephony network using Cisco MCS 7845 Series servers, each one capable of supporting 7500 devices. The design must meet these requirements:

be cost-effective
support up to 7500 phones provide a minimal level of redundancy

Which configuration will meet Ajax Corporation needs?

A.

two Cisco Unified Communications Manager servers:
- 1 publisher and TFTP server combined
- 1 primary subscriber

B.

three Cisco Unified Communications Manager servers:
- 1 publisher and TFTP server combined
- 1 primary subscriber
- 1 backup subscriber

C.

four Cisco Unified Communications Manager servers:
- 1 publisher
- 1 TFTP server
- 1 primary subscriber
- 1 backup subscriber

D.

five Cisco Unified Communications Manager servers
- 1 publisher
- 1 TFTP server
- 1 primary subscriber
- 2 backup subscribers

Showing 10 of 346 questions · Unlock the full set
