Microsoft 74-335 - Questions & Answers

DirectAccess, Its Microsoft new Remote connectivity solution where users on the Internet get Intranet connectivity to their corporate network without installing any client or initiating any software like old traditional VPN.
Microsoft DirectAccess is purely based on IPV6 and Lync 2013 is fully supporting IPV6 and Lync 2013 clients using DirectAccess should work without any problem. If any one encountered problems making Lync calls or connecting to Lync on a DirectAccess Computer then you need to ensure that IPV6 is enabled on the Lync 2013 Server as per the below image.

This can be achieved as follows: Open the Lync 2013 Topology Builder from an old file or download the topology 1.

Edit the properties of the Lync server and in the General Properties ensure that IPV6 2. is enabled.

These settings need to be published from the Action Menu - Topology - Publish 3.
Now you can enjoy Lync 2013 over DirectAccess Connection.

* From scenario:
The company wants to allow only authorized employees to connect remotely. All remote users will use a secure method when remotely connecting to the network and the Lync environment.

Mobile device clients do not support multiple Secure Sockets Layer (SSL) certificates from different domains. Therefore, CNAME redirection to different domains is not supported over HTTPS. For example, a DNS CNAME record for lyncdiscover.contoso.com that redirects to an address of director.contoso.net is not supported over HTTPS. In such a topology, a mobile device client needs to use HTTP for the first request, so that the CNAME redirection is resolved over HTTP. Subsequent requests then use HTTPS. To support this scenario, you need to configure your reverse proxy with a web publishing rule for port 80 (HTTP).

If you support push notifications and want Apple mobile devices to receive push notifications over your Wi-Fi network, you also need to open port 5223 on your enterprise Wi-Fi network. Port 5223 is an outbound TCP port used by the Apple Push Notification Service (APNS).

From scenario: All push notifications must be able to be sent mobile clients on all supported cell phone manufactures. Many users do not use Windows mobile phones.

Ref:
http://technet.microsoft.com/en-gb/library/hh690030.aspx

Note that Microsoft Lync Server 2013 does not support QoS for other Windows operating systems, such as Windows Vista or Windows XP.

The port ranges and DSCPs must be different for audio and video. To create a Quality of Service audio policy for Windows 7 or Windows 8 computers, first log on to a computer where Group Policy Management has been installed. Open Group Policy Management (click Start, point to Administrative Tools, and then click Group Policy Management) and then complete the following procedure:
1. In Group Policy Management, locate the container where the new policy should be created. For example, if all your client computers are located in an OU named Clients then the new policy should be created in the Client OU.

2. Right-click the appropriate container and then click Create a GPO in this domain, and Link it here.

3. In the New GPO dialog box, type a name for the new Group Policy object in the Name box (for example, Lync Audio) and then click OK.

4. Right-click the newly-created policy and then click Edit.

5. In the Group Policy Management Editor, expand Computer Configuration, expand Policies, expand Windows Settings, right-click Policy-based QoS, and then click Create new policy.

6. In the Policy-based QoS dialog box, on the opening page, type a name for the new policy (e.g., Lync Audio) in the Name box. Select Specify DSCP Value and set the value to 46. Leave Specify Outbound Throttle Rate unselected, and then click Next.

7. On the next page, make sure that All applications is selected and then click Next. This setting instructs the network to look for all packets with a DSCP marking of 46, not just packets created by a specific application.
Etc.
