Q4 Single choice

As shown in the figure, after the switch SWA is running RSTP, the administrator configures the port of the G0/0/3 of the SWA as an Edge Port and uses one switch. The machine replaces the host C, and the correct description below is ().

  • A

    The G0/0/3 port of SWA will be closed after receiving the BPDU sent by the switch.

  • B

    The G0/0/3 port of SWA will discard the received BPDU and forward the data normally.

  • C

    The G0/0/3 port of SWA will perform RSTP operation after receiving the BPDU.

  • D

    Among all hosts, only host A can send and receive data normally.
