Q1 Single choice

Exhibit

You are implementing filter-based forwarding to send traffic from the 172.25.0.0/24 network through ISP-1 while sending all other traffic through your connection to ISP-2. Your ge- 0/0/1 interface connects to two networks, including the 172.25.0.0/24 network. You have implemented the configuration shown in the exhibit. The traffic from the 172.25.0.0/24 network is being forwarded as expected to 172.20.0.2, however traffic from the other network (172.25.1.0/24) is not being forwarded to the upstream 172.21.0.2 neighbor.

In this scenario, which action will solve this problem?

  • A

    You must specify that the 172.25.1.1/24 IP address is the primary address on the ge- 0/0/1 interface.

  • B

    You must apply the firewall filter to the lo0 interface when using filter-based forwarding.

  • C

    You must add another term to the firewall filter to accept the traffic from the 172.25.1.0/24 network.

  • D

    You must create the static default route to neighbor 172.21 0.2 under the ISP-1 routing instance hierarchy.
